• 12-volt DC operated
• Open/closed indicator
• Regulating has 4 sec response
• Open / Close verification available
• IP68 waterproof
• -20 to 150F (-29 to 65C) operating
• -67 to 221F (-55 to 105C) storage
• Actuator rated to 250,000 cycles
• Valve rated to 50,000 cycles leak-free
• 100G’s shock rating
• Additional options available including CAN/ISO BUS & Proportional Control.
• Maximum 300 psi
MATERIALS
• 316 stainless steel ball & stem
• Stainless steel hardware
• Fiberglass reinforced polypropylene
• PTFE seats
• FKM stem seals
4 WIRE REGULATING
• Red = +12V DC (Open)
• White = Ground (Open)
• Black = +12V DC (Close)
• Green = Ground (Close)
