• 12-volt DC operated
• Open/closed indicator
• ON/OFF has ¾ second response
• Open / Close verification available
• IP68 waterproof
• -0 to 150F (-18 to 65C) operating
• -67 to 221F (-55 to 105C) storage
• Actuator rated to 500,000 cycles
• Valve rated to 50,000 cycles leak-free
• Additional options available including PWM to CAN/ISO BUS to Bluetooth®* wireless technology.

MATERIALS

• 316 stainless steel ball & stem
• Poly ball available
• Stainless steel hardware
• Fiberglass reinforced polypropylene
• Zinc alloy lower actuator housing
• PTFE seats
• FKM stem seals

ON/OFF

• Red = +12V DC
• Black = Ground
• White = +12VDC (Open)
  0VDC (Close)
